DeltaWASP 60100

Intended for companies with a need to start small production lines, or for prompt prototyping of new designs. The DeltaWASP 60100 was designed with size in mind and developed for huge capacity prints while still retaining the speed of the 4070.

SKU: DW60100 Categories: ,

Accurate and extremely fast for any size print up to 600*1000mm. The 60100 comprises of a heated bed, a controlled ambient environment, and a suspended bowden to guarantee minimal shrinkage and a better final print.

To get the most value out of your delta machine, the LDM WASP extruder and the Spitfire Black extruder are compatible with the DeltaWASP 60100.

Technical Specifications

Cylindrical Print Area: 600mm diametr x 1000mm height
Layer resolution: 100 micron
Nozzle Diameter: 0.4 mm (0.7 mm, 0.9 mm)
Filaments used: 1.75 mm (PLA, ABS, Flex, HIPS, PETG)
Printing maximum speed: 200 mm/s
Travel speed: 200 mm/s

With extruder for fluid-dense materials you can use clay, porcelain, etc…

Operating Systems: WIndows, Mac, Linux
Software slicing: Cura – SLic3r – Simplify 3d
File type: .stl, .obj, .gcode,

SD Card – LCD Screen

Dimensions: 118 x 104 x 254 cm
Machine weight: 100 kg

Dimensions for shipping with wood packaging: 292x132x127 cm, weight 250kg

Input: 220/240V 50/60 Hz
Power Consumption: Max 750W

Use: 20-30 C°
Warehouse: 0-30 C°
Nozzle: max 260 C°
Heat Bed: max 100 C°

Frame and cover: Aluminium, polycarbonate and wood
Printing bed: Steel
Movements: industrial guides on alluminium slides

The system recovers automatically ( when prints are interrupted due to accidental shutdown or blackouts ) interrupted prints in case of accidental shutdown or blackouts.


All available Datasheets are on our downloads page
